New Roof Use Double layer roll forming machine
Payment Type: | L/C,T/T |
---|---|
Incoterm: | FOB,CFR,CIF |
Min. Order: | 1 Set/Sets |
Delivery Time: | 35 Days |
Packaging: | nude in container |
---|---|
Productivity: | 30set/months |
Brand: | dixin |
Transportation: | Ocean |
Place of Origin: | Heibei |
Supply Ability: | 30sets/month |
Certificate: | CE |
HS Code: | 84552210 |
Port: | Tianjin |
Basic Info
Model No.: customized
Product Description
New Roof Use Double layer roll forming machine
component Parts
(1) manual decoiler,used to load coil.
(2) Roll forming part
(3) Hydraulic cutting parts,drived by hydraulic oil Pump.
(4)PLC Control syetem,used to set length,pieces.Control producing.
(5) Receiving table,used to get the roof sheet final products.
Main parameters
Product Name | double layer roll forming machine |
Suitable material | Cold rolled coil,hot rolled coil, galvanized coil |
Q235Mpa.Q350Mpa,Q550Mpa | |
0.3-0.8mm (Customized) 0.2-1.0mm or more | |
Coil | Feeding Width: 1220mm (customized) |
Forming speed | 10-20m/min |
Roller stations | 15 stations |
Material of roller | 45# steel finish maching , plated hard |
Hardness of roller | HRC: 58-62 |
Material of main shaft | 45# steel finish maching , then slack |
Driven motor power | 11Kw |
Hydraulic station power | 7.5 Kw |
Hydraulic station pressure | 12.0 Mpa |
Electrical control system | Panasonic PLC |
Material of cutter | Cr12 MOV |
Hardness of cutter | HRC: 58-62 |
Driving mode | Single chain 1 inch |
Power supply | 380V, 60Hz, 3 Phase or as per request |
Cutting accuracy | ±1.5mm |
Dimension(L*W*H) | 8500mm* 1500mm*1200mm |
Picking and shipping
1.The components will be packed by plastic film and the main roll foming machine in nude with package
2.Delivery :about 30 days after receiving the deposit
3.Port :Tianjin or Qingdao in China
we only do the best, because every customer is very important
Our services
Terms of Payment: 30% of the total contract value paid by T/T as down payment, the rest 70% of the total contract value to be paid by T/T after inspection by buyer in seller`s factory while before delivery.
Delivery: 30 days after receipt of advance payment
Service: we send technician to your country to fix the machine.The buyer should bear all the cost including: visa, Round trip tickets and suitable accommodation, also buyer should pay salary 80USD/day.
Warranty: 12 months limited warranty
During warranty: parts are free but buyer pay for the shipping fee.
Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,Electric Parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
