fuel dispenser diesel nozzle 1" high flow rate
Home > Products > Others > TDW Nozzle > fuel dispenser diesel nozzle 1" high flow rate

fuel dispenser diesel nozzle 1" high flow rate

    Min. Order: 1 Piece/Pieces
    Packaging: Each TDW 7H fuel dispenser nozzle with box, 20pcs in a carton.
    Supply Ability: 1000 Piece/Pieces per Year
    Port: shanghai

Product Description

Fuel Dispenser diesel Nozzle 1" high flow rate Product Description Tested before shipping One year warranty and guarantee Certificate with UL,ATEX,ISO,etc Hot selling in American Factory direct selling
Material
Body Aluminum
Lever and lever guard Duratuff
Main stem Extra hard stainless steel
Seals Buna-N, Viton

Technical Specifical
Working Pressure 0.2 Mpa
Auto Shut-off sensibility 0.1 second
Inlet Size 1"
Thread NPT/BSP
Spout Outlet Diameter 30 mm, 28.7 mm
Flow Rate 20 - 120 L/m
Net Weight 1.55 KG
Order Select
Order Specifications
Item No. Inlet Thread Spout O.D.
TDW-7H01 1" NP 28.7 mm
TDW-7H02 1" NPT 30 mm
TDW-7H03 1" BSP 28.7 mm
TDW-7H04 1" BSP 30 mm

Color Options
Red, Green, Blue, Yellow, Black

Package Data
Size Gross Weight
1pcs = 43*17*6.5 cm (box) 1.7 kg
20pcs = 0.11 club (carton) 34.3 kg
TDW Nozzle Detail fuel dispenser diesel nozzle 1" high flow ratefuel dispenser diesel nozzle 1" high flow ratefuel dispenser diesel nozzle 1" high flow ratefuel dispenser diesel nozzle 1" high flow ratefuel dispenser diesel nozzle 1" high flow rate  Factory Introduce fuel dispenser diesel nozzle 1" high flow rate fuel dispenser diesel nozzle 1" high flow rate fuel dispenser diesel nozzle 1" high flow rate  FAQ&Contact 1- Could you develop our own design? Yes 2- The Fuel Nozzle including swivel? Yes
3- Can we visit your factory? Yes
4- Could you send the sample for testing? Yes
5- Could you offer door to door service? Yes   Contact
Contacts Dustin Chen
WeChat ch739373416
Mob/WhatsApp +86 17805808064
 fuel dispenser diesel nozzle 1" high flow rate

Contact us if you need more details on Dispenser Nozzle. We are ready to answer your questions on packaging, logistics, certification or any Other aspects about Diesel Dispensing Pump、Gasoline Nozzle. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Others > TDW Nozzle
