TDW 7H Fuel dispenser pump parts 1 inch fuel nozzle

TDW 7H Fuel Dispenser Pump Parts 1 inch Fuel Nozzle Product Description Ø Even, Smooth spray pattern - Minimizes diesel foaming and false shut-off
Ø Extra long anchor spring - Keeps the Nozzle secure in most large fill opening.
Ø Help reduces spills - A unique two-stage lever design assures a positive shut-off, even if held wide open.
Ø Three Position hold-open device - One finger control of hold-open mechanism means easy setting of flow rate.
Ø Easily replaced spouts -Simply remove three screws, Replacement kits are readily available from TDW.
Ø Dash-pot Action - For smoother closing action and reduced line shock.
Ø Dual Poppet - Easy to open nozzle against high pressure.
Ø Available with flow lock - Designed to shut off automatically when the spout is tipped ip, limiting spillage.
Ø Suitable for diesel, kerosene, gasoline and gasoline with ethanol blends.
Ø 100% Factory Tested.
Ø TDW-7H UL LISTED.

Material
Body	Aluminum
Lever and lever guard	Duratuff
Main stem	Extra hard stainless steel
Seals	Buna-N, Viton



Technical Specifical
Working Pressure	0.2 Mpa
Auto Shut-off sensibility	0.1 second
Inlet Size	1"
Thread	NPT/BSPT
Spout Outlet Diameter	30 mm, 28.7 mm
Flow Rate	20 - 120 L/m
Net Weight	1.55 KG

  Order Select

Order Specifications
Item No.	Inlet Thread	Spout O.D.
TDW-7H01	1" NPT	28.7 mm
TDW-7H02	1" NPT	30 mm
TDW-7H03	1" BSPT	28.7 mm
TDW-7H04	1" BSPT	30 mm
TDW-7HB01	1" NPT	28.7 mm
TDW-7HB02	1" NPT	30 mm
TDW-7HB03	1" BSPT	28.7 mm
TDW-7HB04	1" BSPT	30 mm



Color Options

Red, Green, Blue, Yellow, Black



Package Data
Size	Gross Weight
1pcs = 43*17*6.5 cm (box)	1.7 kg
20pcs = 0.11 club (carton)	34.3 kg

Packaging & Shipping   You may like our Other automatic nozzles. (Click!!!)
